Theseus 2000 VIS

Theseus 2000 Video Inspection Scope

The Theseus 2000 VIS is a multipurpose video inspection scope developed mainly for use in video assisted medical endoscopic examinations. It makes use of the latest optical and miniature camera technology to provide superior image quality. Coupled with a high resolution monitor and Sony's FVP-1 Mavica printer, it provides a total solution for diagnostic patient examination as well as case history storage.

Key Benefits

	Superior image quality
	Patient information and case history storage
	Cost effective telemedicine

Specifications

High Resolution Colour Monitor
Construction	Metal cabinet, with pebble grey baked enamel
TV System	PAL
CRT Tube	14 " diagonal
Input Signal	RCA composite video
Resolution Centre	650 TV Lines
Power Supply	Mains 220 - 240V AC, 50Hz, 50W
Operation	-5�C to +40�C max 80% humidity
Storage	-25�C to +60�C max 80% Humidity
Dimensions	335mm (L) x 360mm (W) x 315mm (H)
Weight	12kg

Head Unit
Optical Field Of View	40�
Optical Depth Of Field	Near infinite focus (no manual focus adjustment necessary)
Tip Diameter	4.2mm
Distal Tip Length	25mm
Lamp	High intensity low power Halogen filled
Image Sensor	�" inter-line type colour CCD image sensor
Effective Pixels	752 (H) x 582 (V) � 437 664 pixels
Horizontal Resolution	More than 450 TV lines
Automatic Electronic Iris And Gain Control	Provides optimal image intensity (no manual light intensity adjustment necessary)
Automatic Electronic White Balance Control	Provides optimal image colour rendition (no manual colour adjustment necessary)
Operation	-5�C to +40�C max 80% humidity
Storage	-25�C to +60�C max 80% Humidity
Dimensions	120mm (L) x 25mm (W) x 70mm (H)
Weight	200g

Signal Processing/Power Supply Unit
Power Supply	Mains 90 � 264 VAC, 47 � 440 Hz, 10W
TV System	PAL
Inputs	Head unit connector
Outputs	RCA composite video
Operation	-5�C to +40�C max 80% humidity
Storage	-25�C to +60�C max 80% Humidity
Dimensions	150mm (L) x 148mm (W) x 67mm (H)
Weight	400 g

Images

The following images were captured with the Theseus 2000 Video inspection Scope. Most of the images show pathologies of the tympanic membrane. The last images shows the inside of the mouth (a tooth).

To see the original Image, Double Click on the specific image you want to see After viewing the Full Image, use the "BACK" Button on your explorer to return to this page

Pricing

Description	Price
Single unit price	R 35 000.00

Please contact us if you need more information.
