The clutch pot would be wired as follows: wire the center lug to pin #15(+5v output from computer) and the left (opp. of gas) to pin #13(0-5v input from joystick "B" Y axis). If the wiring is different, then you need to determine which axis is not being used. Using my diagram as an example; the X and Y axis of joystick "A" is used, and only the X axis of Joystick "B" is used. Therefore, the Y axis of joystick "B" is left and it is the one you'd use for the clutch. Okay, assuming that you've determined which axis is available, it's simply a matter of consulting the pin assignment chart. Each pot must have a +5v output pin and a 0-5v input pin.
Click here to see a wiring diagram
*Clutch pin assignments, from my wiring diagram, are indicated in red.
|
Pin Chart--Dual Axis |
|
Pin #1 - (+5 volts DC output from computer) Steering, center lug. |
|
Pin #2 - (neg. input from Joystick "A" Button 1) to the NO (normally open) terminal of shifter switch #1 |
|
Pin #3 - (0-5 volts input from Joystick "A" X Axis) Steering, left lug. |
|
Pin #4 - (negative ground output from computer) to the COMMON terminals of shifter switches #1 and #2 |
|
Pin #5 - (negative ground output from computer) no connection |
|
Pin #6 - (0-5 volts input from Joystick "A" Y Axis) Brake, right lug. |
|
Pin #7 - (neg. input from Joystick "A" button 2) to the NO (normally open) terminal of shifter switch #2 |
|
Pin #8 - (+5 volts DC output from computer) |
|
Pin #9 - (+5 volts DC output from computer) Gas & Brake, center lugs. |
|
Pin #10 - (neg. input from Joystick "B" Button 3) (Optional) to one terminal of switch #3 |
|
Pin #11 - (0-5 volts input from Joystick "B" X Axis) Gas, right lug. |
|
Pin #12 - (negative ground output from computer) (Optional) to common terminals of switches #3 & 4 |
|
Pin #13 - (0-5 volts input from Joystick "B" Y Axis) (Clutch, left lug.) |
|
Pin #14 - (neg. input from Joystick "B"Button 4) to one terminal of switch #4 |
|
Pin #15 - (+5 volts DC output from computer) (Clutch, center lug.) |
|
|
